Designed for modulating valve control applications, supporting valve position setpoint, position feedback, remote status, and power status signals, with RS485 Modbus RTU integration into control systems.
Get a Quote
For Seamless Control and Status Feedback of Modulating Valves
The DP motorized modulating valve controller is a seamless controller for modulating valves. Model: DP-VCP-AM.
Input signal: position setpoint (AOI, 4-20mA). Output signals include position feedback (AI, 4-20mA), remote status, and power status.
The product supports RS485 and MODBUS RTU communication, with a configurable communication rate of 9600 bps.
It provides stable position control, position feedback, and remote communication for modulating valves, supporting valve status monitoring and linkage by control systems.
Section Note | This page shows key parameters only. Complete Modbus addresses, wiring diagrams, and installation drawings are available in the downloadable product data. |
Parameter | Details |
Product Type | Seamless controller for modulating valves |
Model | DP-VCP-AM |
Device Power Supply | 220Vac, 50Hz |
Input Signal | Position setpoint (AOI, 4-20mA) |
Output Signal | Position feedback (AI, 4-20mA), remote status (DI, dry contact), power status (DI, dry contact) |
Communication Port | RS485, MODBUS RTU |
Communication Rate | 9600 bps, configurable |
Enclosure Material | ABS engineering plastic (black) |
Installation Method | Panel cut-out mounting |
Cut-Out Dimensions | 75 W × 150 H × 115 D (mm) |
Overall Dimensions | 80 W × 160 H × 120 D (mm) |
Operating Environment | -29℃ to 60℃; 10%-90% RH, non-condensing |
Fault Indication | The valve control module alarms when valve deviation exceeds the set value for the configured duration |
Protection Rating | IP54, PCB: IP65 |
