A locating liquid leak detection module that supports up to 1,500 m of sensing cable, displays the leak alarm location, and enables remote alarm and control via Modbus communication.
Get a Quote
For Liquid Leak Location Detection and Remote Alarm
The DPATL700 is a locating liquid leak detection module for detecting leakage of water, acids, alkalis, oils, and other liquids.
The module can connect up to 1,500 m of sensing cable. When a leak is detected, it displays the leak location on the LCD and outputs a relay alarm signal.
The module supports standard communication protocols and can be networked with other alarm modules or host systems.
It provides liquid leak location detection, alarm output, and remote monitoring for data centers, equipment rooms, and critical facilities.
Section Note | This page shows key parameters only. Complete technical specifications, mounting dimensions, wiring instructions, and selection information are available in the downloadable product data. |
Parameter | Details |
Product Type | Locating liquid leak detection module |
Sensing Cable Length | Maximum cable length: 1,500 m |
Detectable Liquids | Water, acids, alkalis, oils, and other liquids |
Enclosure Dimensions | 70 × 86 × 58 mm |
Enclosure & Protection | Black flame-retardant ABS, IP55 waterproof rating |
Detection Sensitivity | 0-50 KΩ level adjustment, selectable sensitivity, wide detection range |
Accuracy | Detection error less than 2% of cable length |
Power Requirements | 12VDC / 24VAC / 220VAC AC power supply, operating current <1A |
Relay Output | 1 SPDT, rated 220VAC/2A (NO/NC) |
Communication Protocol | RS485 serial interface, MODBUS-RTU protocol |
Communication Rate | 9600 bps |
Default Device Address | 01 |
Installation Method | DIN 35 mm rail mounting |
